LED750W Spot Moving Head Light - BSW - 3IN1

TV-LED750BSW

640W LED Engine 7500K White with CMY function. Dedicated to fulfill the demand of large performance and Theather installation. Read More +

icon_ce

CE Certification

icon_iso

ISO Standards

icon_rohs

RoHS Certificate

light

Light source

Osram LED 640 Module

sun

CMY

Infinite color mixing

heart

COOLING

3 modes of efficient heat dissipation

POWER CONSUMPTION

875W

LED SPOT MOVING HEAD LIGHT WITH CMY

Product Description

Appearance and light effect

TV-LED750BSW Spot moving head light using 640W 7500K White LED Module as the light source. The feature is compact and unique design and light-weight. It is more efficiency for performance.

Excellent optical system

It’s more functional. Excellent fat beam 138MM lens output and strong brightness for the output. Fit CMY color mixing system, and CTO color temperature correction system can precisely control lighting color effect. Set up 3 noise modes for using in different scenes. Very smooth and linear dimmer from 0% to 100%

Characteristics of the product

● Osram LED640W LED Module with 7500K color temperature

● Compact design – Small size and light-weight, but high brightness output

● Fat beam output with lens 138MM

● CMY+CTO color mixing

● Linear dimmer from 0% to 100%

● 3 kinds of noise modes to match with different field

● High CRI ≧ 90

● Soft frost and heavy frost

● Support DMX512, Art-Net, RDM, SACN

Specification

Model TV-LED750
Voltage Voltage:AC100-240V, 50/60Hz
Power Consumption 8570W
Light Source OSRAM 640W White LED Module

Color temperature:7500K – Minimum LED lifetime: 20000 hours

High CRI ≧ 90

Dimming: 0-100% linear dimming

Lighting Effects Pan 540° Tilt 270° (16-bit precision scan )

Dimming: 0-100% linear dimming

Iris: 5%-100% linear adjustment

Soft frost and heavy frost

Zoom range: 4.5°- 50° with motorized

Focus: Motorized

Strobe : Up to 25Hz, random strobe or pulse strobe as optional

Color CMY color mixing – independently variable 0-100%

Color wheel with 6 color filters plus white – Half color + rainbow color – two ways rotation

Prism 4 prisms with two ways of rotation and positioning

High brightness atomized sheets (light/medium) of active type material, can be cut into and stacked

Gobo Rotating gobo wheel: 6 gobos plus white, two ways rotation, and shake

Static gobo wheel: 8 gobos plus open, two ways rotation and shake

Housing High-impact flame-retardant thermoplastic

Color: Black

With folded clamps

Protection rating: IP 20

Working Environment : -10℃-  45℃

Physical Product info: 728*400*263.9 MM; 29.8 KGS

Mater Box Package: 600*585*420 MM ; 34 KGS

Accessories Power Cable * 1

DMX Cable * 1 ( Default 3-pin )

Safety Wire * 2

English User Manual * 1

Connections & Control

DMX and RDM data in/out: 3-pin XLR and 5-pin XLR

AC power input: TRUE1 socket

Control Mode : DMX512,Art-net,RDM,sACN

DMX Channels: 27/34

Wireless DMX 512 Control ( Optional )

Touchable LCD screen ( Default English )

Video of TV-LED750W

WIDE RANGE OF APPLICATIONS

Suitable for large-scale concerts, stage performances, theatres, television studios, lighting projects, exhibitions.
